Schiit Yggdrasil+'s unique True Multibit™ architecture combines integrated multibit D/A converters with a proprietary time.
74.990.000 ₫
Vận chuyển
Miễn phí vận chuyển cho đơn hàng từ 1.000.000 VNĐ
All Schiit Yggdrasil+ versions use our True Multibit architecture, a unique combination of our proprietary time- and frequency-domain optimized digital filter and integrated, medical/defense grade multibit D/A converters. Yggdrasil’s DSP-based digital filter has a closed-form solution—it retains the original samples, performing a true interpolation. Only this digital filter gives you the best of both NOS and upsampling designs.
Yggdrasil+ isn’t just about ultimate performance. At the same time, we’ve included 5 digital inputs, including our own Unison USB™ interface with complete electromagnetic and electrostatic isolation. Ease of access is assured with standard remote control, and we’ve provided features like absolute phase inversion and NOS mode so you can optimize for your individual system and recordings.
Thông số chi tiết
THD:
Less than 0.0002%, 20Hz-20KHz, at full output
IMD:
<0.0005%, CCIF, at full output
Model
Schiit Yggdrasil+ MIL (More Is Less)
SNR:
> 123dB, referenced to 4V RMS
Analog Stage:
Integrated, using LME49724 differential stage
Maximum Output:
4.0V RMS (balanced), 2.0V RMS (single-ended)
D/A Conversion IC:
Texas Instruments DAC11001 (2 per channel, hardware balanced configuration)
Frequency Response, Analog Stage:
20Hz-20Khz, +/-0.1dB, 0.5Hz-200KHz, -1dB
