Schiit Lyr+

Thương hiệu:

Schiit Lyr+ là bộ khuếch đại đầu nhỏ gọn sử dụng công nghệ Fusion Architecture™ độc quyền của Schiit Audio với công suất ấn tượng.


19.990.000 ₫

Phiên bản kèm bóng 6SN7

Bảo hành

1 năm


Thông tin chi tiết

Want a super-high-end, super-powerful, tube hybrid headphone amp and preamp—but also want the comfort of a pure solid state design? Then Schiit Lyr+ is for you! It’s the only headamp in the world that goes seamlessly from tube to solid state, using our exclusive Fusion Architecture™.

Introducing about Schiit Lyr+

Schiit Lyr+ switches seamlessly to its internal solid state gain stage, based on exotic depletion-mode MOSFETs. Want tube gain? Then plug in any 6SN7-type tube, and Lyr+ switches over to 100% tube voltage gain with the MOSFETs completely out of the picture. That’s the magic of Fusion Architecture.

1. Technological Tour De Force

Schiit Lyr+ is our first compact headamp that gives you relay ladder volume control, for ultimate transparency and perfect channel matching, from the lowest to highest volumes. Coupled with a powerful Continuity™ bipolar output stage, full DC coupling throughout, separate regulated high-voltage and low-voltage supplies, the convenience of remote control (in case you want to use it, say, off the desktop), and microprocessor oversight, Lyr+ is a small marvel.

2. Power and Safety in One

Lyr+ delivers up to 6W RMS per channel through the standard ¼” headphone jack, so there’s no need for balanced headphones to take advantage of all that power. But, at the same time, advanced oversight ensures Lyr+ is safe for every headphone. DC, overcurrent, and tube sensing means this is a fully modern tube amp.

3. The Heart of a Complete, Compact System

Add Bifrost 2 or Modius for digital duties, and a Vidar or Aegir as a speaker amp, and Lyr+ is the heart of a full system, ready for headphones, speakers, and both analog and digital sources. You can even turn off Schiit Lyr+’s preamp outs, if you just want to listen to headphones.

Thông số chi tiết

GainHigh 5.7 (15dB), Low 1.2 (1.35dB)
ModelSchiit Lyr+
Size9 x 6 x 2”
Weight6 lbs
TopologyCoherence ™ fully discrete, current-mode noninverting 6SN7/bipolar hybrid with constant transconductance output stage with Fusion Architecture™ depletion MOSFET gain fallback, 64-step relay ladder volume control
ProtectionMicroprocessor oversight for high DC, over-current, and tube presence; mute on any fault and management of tube and solid state gain modes
Power Supplytwo internal power transformers with 72VA total rating, plus with over 55,000uf of filter capacitance; two discrete regulated +/-100V supplies, two high-current +/-26V supplies, four regulated oversight supplies—20V, +/-15V, 5V
Power Consumption30W
Tube Mode, Low GainTHD: > 0.003%, 20Hz-20KHz, at 2V RMS, 32 ohms IMD: > 0.003%, CCIR at 2V RMS SNR: -70dB, 20Hz-20KHz, 32 ohms Output Impedance: 0.4 ohms
Tube Mode, High GainTHD: >0.0003%, 20Hz-20KHz, at 2V RMS IMD: > 0.0003%, CCIR at 2V RMS SNR: -95dB, 20Hz-20KHz Output Impedance: 75 ohms
Solid State Mode, Low GainTHD: >0.0015%, 20Hz-20KHz, at 2V RMS, 32 ohms IMD: > 0.001%, CCIR at 2V RMS, 32 ohms SNR: -72dB, 20Hz-20KHz, 32 ohms Output Impedance: 0.4 ohms
Solid State Mode, High GainTHD: >0.003%, 20Hz-20KHz, at 2V RMS, 300 ohms IMD: > 0.003%, CCIR at 2V RMS, 32 ohms SNR: -85dB, 20Hz-20KHz, 32 ohms Output Impedance: 0.6 ohms
All Tube and Solid State ModesFrequency Response: 20Hz - 20Khz, +/-0.08dB Maximum Power, 16 ohms: 9.0W RMS per channel Maximum Power, 32 ohms: 6.0W RMS per channel Maximum Power, 50 ohms: 4.0W RMS per channel Maximum Power, 300 ohms: 900mW RMS per channel Maximum Power, 600 ohms: 450mW RMS per channel
Preamp Output, Low Gain, Solid StateTHD: >0.0003%, 20Hz-20KHz, at 2V RMS IMD: > 0.0025%, CCIR at 2V RMS SNR: -90dB, 20Hz-20KHz Output Impedance: 75 ohms
