Devialet Expert 440 Pro Dual

Thương hiệu

499.000.000

Bảo hành

Bảo hành 24 tháng

Thông tin chi tiết

Xem thêm

Thông số kỹ thuật

RANGE

Dual-Mono

EXCLUSIVE TECHNOLOGIES

ADHV2®, SAM®, AIR®, EVO®, DAC Magic Wire®, RAM®

STREAMING SERVICES

UPnP

Airplay®

Spotify Connect

DAISY CHAINING

Up to 8 units

PHONO STAGE

Advanced (MM / MC)

PRE-AMPLIFIED OUTPUT

Yes (mono / stereo)

CASING

Carved out from a single aluminium block

SIDE PLATING

Dark chrome finish

DIMENSION

Length: 400mm | Width: 400mm | Height: 40mm

WEIGHT

Master : 5.9Kg ; Companion : 5.4Kg

POWER

2x440WRMS 6Ω

DISTORTION AT FULL POWER

0,00025%

DISTORTION AT 10W

0,0001%

SIGNAL-TO-NOISE RATIO

133dB

OUTPUT IMPEDANCE

0,001Ω

DAMPING FACTOR

8000

BANDWIDTH

DC-30kHz (-0.1dB) DC-95kHz (-3dB)

PHASE ROTATION

0.2° at 20kHz

0.9° at 40kHz

THERMAL DISTORSION

Below measurement threshold

INTELLIGENCE

3 x SHARC 400 MHz DSP’s

1 x 16 MHz RISC processor

4 x 40 MHz RISC processors

1 x 64 MHz RISC processor

WI-FI

2.4GHz 802.11 b/g/n Wi-Fi input for the Devialet AIR universal streamer

Supported formats: 16-bit/44.1 kHz PCM to 24-bit/192 kHz PCM

ETHERNET

RJ45 100/1000 Mbps

USB

USB Audio 2.0 asynchronous input/output

    Supported formats:

  • 16-bit/44.1 kHz PCM to 32-bit/192 kHz PCM
  • DSD64 1bit/2.822400MHz and 1bit/3.072000MH
    Special characteristics:

  • Very low latency
  • Bi-directionality for digitisation of the active source

DIGITAL COAXIAL INPUTS

    Supported formats:

  • 16-bit/44.1 kHz PCM to 24-bit/192 kHz PCM
  • DSD64 1bit/2.822400MHz and 1bit/3.072000MHz

DIGITAL OPTICAL INPUTS

Supported formats:

16-bit/44.1 kHz PCM to 24-bit/192 kHz PCM

SUPPORTED FORMATS

Up to 32bits / 192kHz PCM (USB)

Up to 24bits / 192kHz PCM (AIR®, UPnP, AES/EBU, Coaxial)

Up to 24bits / 96kHz PCM (Optical)

Up to 1bit / 3.072000MHz DSD64 (USB, Coaxial)

ANALOG INPUTS

Up to 4x RCA stereo

Sensitivity adjustable via the Configurator

Advanced phono stage (MM / MC)

SPEAKER OUTPUT

4mm banana plugs, stripped cables or fork connectors

Adjustable from 30 WRMS to 440 WRMS via the configurator

Compatible with all speakers, from 1Ω to 16Ω

Short-circuit protection

Active filtering available

Output impedance: 0.001Ω

HOME AUTOMATION

Up to 1x RS232 3.5mm 115200 bauds (documentation available via the configurator)

TRIGGER

3.5mm mini-jack trigger connector
